chipset: ALi M1631/M1535D (ALADDiN TNT2) - ALi M1631/M1535D (ALADDiN TNT2)
cpu socket: socket 370 (PGA370)
speed FSB: 66MHz * 100MHz * 133MHz speeds
form factor: microATX (max 244 x 244 mm)
dimensions:: 244mm x 210mm
cache: none / Integrated in the CPU
max RAM size: 1Gb
ram type: SDR UDIMM
pwr PSU connector: ATX 1.x (20-pin ATX)
conn: I/O ports
1x 3.5mm audio combo
1x floppy interface
1x Gameport
2x IDE interface
1x IrDA
1x PS/2 keyboard
1x PS/2 mouse
1x Parallel
1x RJ-45 LAN
2x Serial ports
2x USB 1.x
Expansion slots: 3x 32-bit PCI
designed also as:
Totem TM-A1631LM
PCChips/ Hsin Tech M754LMR
Amptron PIII-3754 LMR
|
